VENTIS-AJ

VENTIS-AJ fibre laser - High processing speed, unrivalled cutting quality

The VENTIS-AJ is the biggest innovation in sheet metal cutting and introduces the next generation of fibre laser processing machines.
What makes this technology truly revolutionary is the innovative beam shaping system that allows for precise control of the laser beam motion. The new, AMADA 4 kW single diode module fibre laser engine provides a very high quality laser beam, allowing the VENTIS-AJ to be comparable to 6-8 kW machines, with much less power requirements and an unrivalled cutting quality.

BROCHURE

LBC TECHNOLOGY

LBC is an innovative system for controlling the laser beam motion. It manages beam pattern during the cutting process. The geometry of this pattern is variable for each thickness and material to be processed. The power of the beam no longer needs to be diffused to cut any materials. This guarantees very high processing speeds and a remarkable cutting quality.

SINGLE MODULE AMADA FIBRE LASER ENGINE

AMADA was the first laser machine manufacturer worldwide to develop its own fibre laser engine in-house, specifically designed for cutting. With a single, 4 kW diode module and no combiner, the quality of the laser beam generated is industry leading.

DROSS FREE PROCESSING

With LBC technology that can monitor and control the laser beam pattern, it is possible to achieve an industry first: Cutting of mid-thick non-ferrous metals without dross. This has significant benefits, such as removing secondary operations and improving part flow through the factory.

ADAPTABLE KERF WIDTH CONTROL

Due to the nature of the LBC technology and the ability to change the laser beam cutting pattern, cutting kerfs greater than conventional machines can be produced. This makes it much easier to remove thick parts manually, or thin-to-medium thick parts with an automated part picking system.

NEW NUMERICAL CONTROL

The new AMADA AMNC 3i numerical control ensures outstanding performance and maximises productivity by automatically optimising rapid laser head movements between each cut.

AUTOMATIC NOZZLE CHANGER

To ensure continuous, automatic operation, the VENTIS-AJ has a 16-station nozzle change system which includes a head calibration and nozzle cleaning unit.

Hotspots

SINGLE-DIODE MODULE ENGINE:

With a single, 4 kW module engine and no combiner, the quality of the laser beam is industry leading.

BEAM CONTROL:

Innovative control of the high-density laser beam can oscillate the beam during cutting, following predefined paths for high-speed, precision processing.

SIDE DOOR:

The VENTIS-AJ has been fitted with large front and side opening doors, for more convenient and flexible access to the cutting area.

SINGLE-DIODE MODULE ENGINE:

With a single, 4 kW module engine and no combiner, the quality of the laser beam is industry leading.

BEAM CONTROL:

Innovative control of the high-density laser beam can oscillate the beam during cutting, following predefined paths for high-speed, precision processing.

SIDE DOOR:

The VENTIS-AJ has been fitted with large front and side opening doors, for more convenient and flexible access to the cutting area.

	VENTIS-3015AJ	VENTIS-4020 AJ
Laser power (W)	4000	4000
Machine type	Fibre laser cutting machine	Fibre laser cutting machine
Working range X x Y (mm)	3070 x 1550	4070 x 2050
Working range Z-axis (mm)	100	100
Repeatable positioning accuracy (mm)	± 0.01	± 0.01
Table loading weight (kg)	920	1570
Drive system	Helical rack and pinion	Helical rack and pinion
*Material thickness (max.):**
- Mild steel (mm)	25	25
- Stainless steel (mm)	20	20
- Aluminium (mm)	16	16
- Brass (mm)	10	10
- Copper (mm)	8	8
Dimensions:
Length (mm)**	10060	12035
Width (mm)	2840	3340
Height (mm)	2432	2432
Weight (kg)	9200	12300

* Maximum thickness value depends on material quality and environmental conditions
** Machine + shuttle table (LSTe)

Technical data can vary depending on configuration / options
Please contact us for more details and options or download our brochure

For your safe use.
Be sure to read the user manual carefully before use.
When using this product, appropriate personal protection equipment must be used.

Laser class 1 when operated in accordance to EN 60825-1
